Java Development Tools

JUnit

Java Editor

Custom Folding Regions It is now possible to create custom folding regions by specifying a comment at the start and end of the region. You can enable and configure this feature under Window > Preferences > Java > Editor > Folding > Custom folding regions. Preference page for custom folding regions

on that preference page, you can specify the text that should be used to start and end a custom folding region. When this is enabled, writing a comment starting with the specified region start followed by another comment starting with the specified region end creates a folding region.

code containing comments with the text 'region' and 'endregion'

Custom folding regions can be collapsed like any other folding regions.

custom folding regions are collapsed
Project Properties Page for Folding Preferences for folding can now be configured on a per-project basis in addition to configuring folding for the workspace. This page is available under Project > Properties > Java Editor > Folding.

Project Properties page for folding
New folding mechanism as Default In the previous release, a preference to enable different kinds of folding was introduced (see the news for 4.35). The feature has been further improved since then and is now enabled by default.

This feature enhances the code folding mechanism in Eclipse JDT by enabling folding for control statements such as if, while, switch, and for. It improves code readability and navigation by allowing developers to collapse and expand structured blocks.

View of the new folding

The feature can be disabled in the settings under Java > Editor > Folding.

Settings view of the folding

Java Views and Dialogs

Java Compiler

Java Formatter

Debug

Collapsing Stack Frames Navigating in deep stack frames can be challenging during debuging, due to the high number of stack frames that are not relevant most of the time, for example because they are provided by either the JDK, by a testing framework, or by a library. This feature tries to help focus on the stack frames that are coming from the user-created projects, drastically reducing the unnecessary noise in the Debug View.

Original

The feature can be enabled from the Debug toolbar in Debug > Java > Collapse Stack Frames.

Menu to enable

After enabling it, the view becomes much simpler and less intimidating:

Collapsed stack frames
Auto-Resuming Trigger Points Trigger points can now be configured to automatically resume execution when hit, allowing breakpoints after the trigger point to be activated while skipping those before it, thereby enabling a more focused and efficient debugging workflow.

Upon enabling a trigger point, a new option will be shown to Continue execution on hit or not.

Triggerpoint Enabled

Once Continue execution on hit is toggled, the breakpoint label will update to [Resume on hit] meaning it won't suspend on hit.

Triggerpoint Continue

Resume trigger also supports conditions, meaning if condition is true it will resume the execution otherwise it will suspend.

Resume-Triggerpoint with conditions

Now when you run in debug mode, the trigger point won't hit, allowing you to skip previous breakpoints, and stop on the actual breakpoint on which you need to focus.

For example, here Resume trigger was set on line number 7 and during debugging it hit on line number 8 by skipping all the previous breakpoints.

Resume-Triggerpoint execution
